China OEM High Quality140MM 160MM 168MM 200MM Steel UPVC Big Size Ball Valve For Project DN200 officinas and manufacturers |Pntek

OEM High Quality140MM 160MM 168MM 200MM Steel UPVC

Description:

Pila valvae
1.Soft colores & Foedus design
2.Leakproff operatio;
3.Light ac communione finem faciunt facilem institutionem
4.Economic ut vilis onerariis criminibus & diu operantes vita
5.Well et princeps qualis imperium
6.Environment amica, non-toxic
7.Weathering & Abrasion resistentia & optimum chemica resistentia
8.Widely in aedificationem, irrigationem, industriam et lacus
9.Small ordinem gratum
10.Customer de consilio & logo sunt grata

Magnitudo:140MM 160MM 168MM 200MM

Iuncturam finem:ASTM BS DIN ISO JIS

Pressura opus:PN16

Mitte ad nos inscriptio

Product Detail

FAQ

Product Tags

Legenda et tabula physica

singleproducimg

Component material

speciem materialem

NO.	Pars	Materia	QTY
1	CORPUS	UPVC, CPVC	1
2	STEM O-Ringo	EPDM,FPM(NBR)	1
3	STEM	UPVC, CPVC	1
4	SPHERA	UPVC, CPVC	1
5	SEDES SIGNACULUM	TPE,TPVC,TPO	2
6	CAP	PVC, ABS	1
7	CAPULUS	PVC, ABS	1
8	COCHLIA	SS304, STEEL	1

Exemplar magnitudine parametri comparationis in mensa

DIMENSIONE												Unitas
EXEMPLUM	DN		15	20	25	32	40	50	65	80	100
	MENSURA		1/2"	3/4"	1"	1-1/4"	1-1/2"	2"	2-1/2"	3"	4"	Inch
	thd./in	NPT	14	14	11.5	11.5	11.5	11.5	8	8	8	mm
	thd./in	BSPT	14	14	11	11	11	11	11	11	11	mm
	JIS	I	20	20	24	26	30	31	45	48	53	mm
		d1	22.3	26.3	32.33	38.43	48.46	60.56	76.6	89.6	114.7	mm
		d2	21.7	25.7	31.67	37.57	47.54	59.44	75.87	88.83	113.98	mm
	ANSI	I	18	20	24	26	30	31	45	48	53	mm
		d1	21.54	26.87	33.65	42.42	48.56	60.63	73.38	89.31	114.76	mm
		d2	21.23	26.57	33.27	42.04	48.11	60.17	72.85	88.7	114.07	mm
	DIN	I	18	20	24	26	30	31	45	48	53	mm
		d1	20.3	25.3	32.3	40.3	50.3	63.3	75.3	90.3	110.4	mm
		d2	20	25	32	40	50	63	75	90	110	mm
	d		15	19	24	30	34	45	55	70	85	mm
	H		37	55	66	73	81	91	99	121	134	mm
	A		68	80	94	100	110	136	170	210	236	mm
	L		77	91	103	111	123	146	178	210	255	mm
	D		32	37.5	44	52	60	74	93	110	135	mm
